Product Description

Dimplex PLXE Electric Panel Heater 1KW

Model:PLX0100E

Dimplex PLX100e Range of Wall Mounted Panel Heaters are LOT20 compliant with new feature

The PLXE range  is Eco-Design compliant, modern and efficient electric panel heater. Offering intuitive controls with multiple timers, natural white colour and louvered grille, this heater will fit naturally into any room.

Dimplex PLX Range PLX100E Specification:

• Dimplex PLX100E Heater Manual
• Finish – Traffic white (RAL 9016)
• Width – 620 mm
• Height – 430 mm
• Depth – 108 mm
• Heat Output – 1KW
• IPX4 rated – Splashproof
• Thermostat controled
• Digitally Controlled
• Electronic Timer modes
• 7 Day Programmable User Timer
• Out All Day, Home All Day, Holiday Continuous heat modes: Timer, Eco, Manual, Frost Protect, Runback, Off
• Simple To Use Controls

Where Can I Install My Panel Heater?

• Bedroom Yes
• Kitchen Yes
• Bathroom Yes
• Conservatory Yes
• Living room Yes
• Dining Room Yes
• Attic Conversion Yes
• Study Yes
• Hallways & Landings Yes

WARNING:This item must be installed where it is impossible for switches or other controls to be touched by a person using bath or shower.

TThis panel heater features the CapSense controller, providing a more intuitive user experience with its backlit LCD display and touch-sensitive buttons.

Adaptive Start pre-heats the room ahead of a programmed heating schedule for only exactly the amount of time required to meet the desired target temperature at the desired time. For example, if the product was following a timer which was set to 21 degrees at 7am, with Adaptive Start the product will begin heating before 7am to achieve 21 degrees at 7am, without Adaptive Start the heater will only begin heating at 7am.

Open Window detection monitors the room temperature while the heater attempts to achieve a desired room temperature. If the room temperature does not change or decreases while heat is being emitted, the product will stop heating and enter a standby mode in order to not waste energy.

This panel heater is also splash-proof for use in bathrooms and complies with Lot 20 of ERP Directive.

Please Note: These heaters need to be hard wired into your electrical system.

Guarantee Terms:

Extra care must be taken to avoid damaging the electric panel heater when installing. Dimplex offer a 2 year guarantee against faulty workmanship or materials (excluding serviceable parts, neglect or abuse).
