Product Description

TWPro 125mm Adjustable Wall Support 80–137mm – Matt Black

Model: 58-125-052

Secure a vertical TWPro chimney to an external wall with this 125mm adjustable twin-wall support bracket. The bracket provides lateral support and lets you position the chimney approximately 80mm to 137mm from the wall.

Its adjustable design helps accommodate gutters, roof overhangs and uneven wall surfaces. In addition, the matt-black finish matches TWPro black twin-wall pipe and fittings.

Please note: this bracket provides lateral support only. It does not carry the vertical weight of the chimney.

Key Features

• Designed for 125mm TWPro and compatible KW Flue systems
• Adjustable wall clearance from approximately 80mm to 137mm
• Provides lateral support for a vertical chimney
• Helps keep external flue sections stable and correctly aligned
• Suitable for internal or external installation
• Durable matt-black finish
• Use at intervals of no more than 3 metres, subject to the installation design
• Product model: 58-125-052

Adjustable Wall Clearance

The adjustable arms let the installer set the distance between the building surface and the chimney. Therefore, the bracket can help the flue clear small obstacles while maintaining a straight and secure route.

Before ordering, measure from the finished wall surface to the required position of the chimney. Also allow for the chimney’s approximate 175mm outside diameter and its required clearance from combustible materials.

Lateral Support Only

This wall bracket controls sideways movement and helps keep the chimney vertical. However, it does not support the chimney’s vertical load. Consequently, the installation may also require a suitable base support, wall support plate, ceiling support or other load-bearing component.

Install wall supports at intervals of no more than 3 metres unless the TWPro instructions or site conditions require closer spacing. Additional support may also be necessary near offsets, changes of direction or exposed sections.

Compatibility

This bracket fits the 125mm internal-diameter TWPro twin-wall system. Because the system contains 25mm of insulation around the inner flue, its main outside diameter measures approximately 175mm.

This support only fits compatible TWPro and KW Flue pipe and fittings. It is not interchangeable with other twin-wall chimney brands. Never mix different systems unless the manufacturer confirms compatibility in writing.

TWPro 125mm Adjustable Wall Support Specification

• Download the TWPro Matt Black information sheet
• View the TWPro installation guide
• Read why we recommend TWPro twin-wall flue
• Product type: adjustable lateral wall support
• Nominal flue diameter: 125mm internal
• Approximate system outside diameter: 175mm
• Adjustment range: approximately 80mm to 137mm from the wall
• Function: lateral support only
• Maximum standard spacing: 3 metres, subject to the installation design
• Finish: matt black
• Compatibility: TWPro and compatible KW Flue systems only
• System warranty: 25 years, subject to terms and conditions
• Paint-finish warranty: 2 years, subject to terms and conditions

Installation Guidance

Fix the bracket to a strong and suitable building surface. In addition, use fixings that suit the wall construction and the loads created by the chimney and local wind conditions.

Do not rely on lightweight cladding, render or insulation to support the bracket. Instead, secure the fixings into a suitable structural surface. If necessary, ask a qualified professional to specify the correct anchors.

Next, adjust both arms evenly so the chimney remains vertical. Then tighten every fixing securely and check that the bracket grips the pipe without damaging its outer casing.

Wall supports do not replace structural load-bearing components. Therefore, the complete chimney design must include the correct supports for its height, weight, offsets and exposed sections.

Clearance from Combustible Materials

The TWPro chimney system carries a G50 designation at T600. As a result, the system requires a minimum declared clearance of 50mm from combustible materials under the stated test conditions.

However, the adjustable distance from the wall does not automatically confirm a compliant installation. Wall construction, roof details and nearby materials must all be considered. If another part of the installation requires a greater clearance, always follow the greater distance.

TWPro System Approvals

• HETAS-approved chimney system
• CE marked: EN 1856-1 T600 N1 W V2 L50040 G50
• CE marked: EN 1856-1 T200 P1 W V2 L50040 O20

These classifications apply to the complete TWPro chimney system when installers use approved components and follow the manufacturer’s instructions.

About the TWPro Twin-Wall Flue System

TWPro offers a complete insulated stainless-steel chimney system for compatible wood-burning, multifuel, gas and oil appliances. Its push-fit FitSystem joints and locking bands make compatible pipe sections quick to connect.

Furthermore, the smooth matt-black finish creates a neat appearance on external chimney routes. Matching lengths, bends, supports, flashings and terminals are available to complete the installation.

Why Buy from SNH Tradecentre?

• Specialist stove, chimney and flue-system supplier
• Extensive range of matching TWPro components
• Practical product advice from an experienced team
• Nationwide UK delivery options
• Secure online ordering
• Trade counter in Birchington, Kent
• Support before and after your purchase

Need help choosing the correct wall bracket or structural support? Call SNH Tradecentre on 01843 842727 before ordering.

Frequently Asked Questions

What adjustment does this wall support provide?

The bracket positions the chimney approximately 80mm to 137mm from the finished wall surface. Check the latest technical drawing before ordering because the exact measurement may depend on the fixing position.

Does this bracket carry the chimney’s weight?

No. It provides lateral support only. The chimney requires suitable load-bearing supports elsewhere in the installation.

How often should I fit a wall support?

Fit supports no more than 3 metres apart unless the system instructions, chimney height or site conditions require closer spacing.

What size pipe does it fit?

It fits compatible TWPro and KW Flue systems with a 125mm internal diameter. The matching twin-wall pipe has an approximate outside diameter of 175mm.

Will it fit another brand of twin-wall flue?

No, unless the manufacturer confirms compatibility in writing. Different chimney brands use different dimensions, joints and support arrangements.

Are wall fixings included?

Always check the supplied contents before installation. The correct wall fixings depend on the building material, so the installer must select suitable structural anchors for the site.

Can I fix it to a combustible wall?

The bracket may attach to a suitable structural wall, but the chimney must still maintain its required clearance from every combustible material. The TWPro system declares a minimum distance of 50mm at T600.

Who should install the support?

A suitably competent installer should design and install the chimney system. For solid-fuel installations, consider using a HETAS-registered installer.
